Firewall general :
Operating system : SonicOS 6.5.1
Security processing cores : 24
Interfaces :
4 x 10-GbE SFP+,
8 x 1-GbE SFP,
8 x 1-GbE,
1 GbE Management,
1 Console
Expansion:1 Expansion Slot (Rear)*, SD Card*
Management :CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
SSO users:70,000
Maximum access points supported : 128
Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
Firewall inspection throughput : 12.0 Gbps
Full DPI throughput : 3.0 Gbps
Application inspection throughput : 4.5 Gbps
IPS throughput : 4.5 Gbps
Anti-malware inspection throughput : 3.0 Gbps
IMIX throughput : 3.5 Gbps
TLS/SSL decryption and inspection (DPI SSL) : 1.3 Gbps
VPN throughput : 5.0 Gbps
Connections per second : 90,000/sec
Maximum connections (SPI) : 1,500,000
Maximum connections (DPI) : 1,000,000
Default/Maximum connections (DPI SSL) : 6,000/10,500
VPN :
Site-to-site VPN tunnels : 6,000
IPSec VPN clients (max) : 2,000 (6,000)
SSL VPN NetExtender clients (max) : 2 (1,500)
Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN : RIP, OSPF, BGP
Networking :
IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
VLAN interfaces : 256
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
VoIP : Full H323-v1-5, SIP
Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering
Hardware :
Power supply : Single, Fixed 250W
Fans : Dual, redundant, hot swappable
Input power : 100-240 VAC, 60-50 Hz
Maximum power consumption (W) : 113.1
MTBF @25ºC in hours : 116,477
MTBF @25ºC in years : 13.30
Form factor : 1U Rack Mountable
Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
Weight : 14.93 lb (6.77 kg)
WEEE weight : 19.78 lb (8.97 kg)
Shipping weight : 26.12 lb (11.85 kg)
Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity : 10-90% non-condensing
Firewall general :
Operating system : SonicOS 6.5.1
Security processing cores : 10
Interfaces :
2 x 10-GbE SFP+,
4 x 1-GbE SFP,
12 x 1-GbE,
1 GbE Management,
1 Console
Expansion:1 Expansion Slot (Rear)*, SD Card*
Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
SSO users : 60,000
Maximum access points supported : 96
Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
Firewall inspection throughput : 9.0 Gbps
Full DPI throughput : 1.6 Gbps
Application inspection throughput : 3.0 Gbps
IPS throughput : 3.0 Gbps
Anti-malware inspection throughput : 1.7 Gbps
IMIX throughput : 2.4 Gbps
TLS/SSL decryption and inspection (DPI SSL) : 800 Mbps
VPN throughput : 4.5 Gbps
Connections per second : 60,000/sec
Maximum connections (SPI) : 1,500,000
Maximum connections (DPI) : 1,000,000
Default/Maximum connections (DPI SSL) : 4,000/8,500
VPN :
Site-to-site VPN tunnels : 4,000
IPSec VPN clients (max) : 2,000 (4,000)
SSL VPN NetExtender clients (max) : 2 (1,000)
Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN : RIP, OSPF, BGP
Networking :
IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
VLAN interfaces : 400
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
VoIP : Full H323-v1-5, SIP
Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
High availability : Active/Passive with State Sync, Active/Active DPI with State Sync, Active/Active Clustering
Hardware :
Power supply : Single, Fixed 250W
Fans : Dual, Fixed
Input power : 100-240 VAC, 60-50 Hz
Maximum power consumption (W) : 90.9
MTBF @25ºC in hours : 134,900
MTBF @25ºC in years : 15.40
Form factor : 1U Rack Mountable
Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
Weight : 13.56 lb (6.15 kg)
WEEE weight : 14.24 lb (6.46 kg)
Shipping weight : 20.79lb (9.43 kg)
Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity : 10-90% non-condensing
Firewall general :
Operating system : SonicOS 6.5.1
Security processing cores : 8
Interfaces :
2 x 10-GbE SFP+,
4 x 1-GbE SFP,
12 x 1-GbE,
1 GbE Management,
1 Console
Expansion:1 Expansion Slot (Rear)*, SD Card*
Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
SSO users : 50,000
Maximum access points supported : 64
Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
Firewall inspection throughput : 6.0 Gbps
Full DPI throughput : 800 Mbps
Application inspection throughput : 2.0 Gbps
IPS throughput : 2.0 Gbps
Anti-malware inspection throughput : 1.1 Gbps
IMIX throughput : 1.6 Gbps
TLS/SSL decryption and inspection (DPI SSL) : 500 Mbps
VPN throughput : 3.0 Gbps
Connections per second : 40,000/sec
Maximum connections (SPI) : 1,000,000
Maximum connections (DPI) : 500,000
Default/Maximum connections (DPI SSL) : 3,000/4,500
VPN :
Site-to-site VPN tunnels : 3,000
IPSec VPN clients (max) : 500 (3,000)
SSL VPN NetExtender clients (max) : 2 (500)
Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN : RIP, OSPF, BGP
Networking :
IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
VLAN interfaces : 256
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
VoIP : Full H323-v1-5, SIP
Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
High availability : Active/Passive with State Sync, Active/Active Clustering
Hardware :
Power supply : Single, Fixed 250W
Fans : Dual, Fixed
Input power : 100-240 VAC, 60-50 Hz
Maximum power consumption (W) : 86.7
MTBF @25ºC in hours : 139,783
MTBF @25ºC in years : 15.96
Form factor : 1U Rack Mountable
Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
Weight : 13.56 lb (6.15 kg)
WEEE weight : 14.24 lb (6.46 kg)
Shipping weight : 20.79lb (9.43 kg)
Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity : 10-90% non-condensing
Firewall general :
Operating system : SonicOS 6.5.1
Security processing cores : 6
Interfaces :
2 x 10-GbE SFP+,
4 x 1-GbE SFP,
12 x 1-GbE,
1 GbE Management,
1 Console
Expansion:1 Expansion Slot (Rear)*, SD Card*
Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
SSO users : 40,000
Maximum access points supported : 48
Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
Firewall inspection throughput : 3.4 Gbps
Full DPI throughput : 500 Mbps
Application inspection throughput : 1.1 Gbps
IPS throughput : 1.1 Gbps
Anti-malware inspection throughput : 600 Mbps
IMIX throughput : 900 Mbps
TLS/SSL decryption and inspection (DPI SSL) : 300 Mbps
VPN throughput : 1.5 Gbps
Connections per second : 20,000/sec
Maximum connections (SPI) : 750,000
Maximum connections (DPI) : 375,000
Default/Maximum connections (DPI SSL) : 2,000/2,750
VPN :
Site-to-site VPN tunnels : 1,000
IPSec VPN clients (max) : 50 (1,000)
SSL VPN NetExtender clients (max) : 2 (350)
Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN : RIP, OSPF, BGP
Networking :
IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
VLAN interfaces : 256
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
VoIP : Full H323-v1-5, SIP
Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
High availability : Active/Passive with State Sync, Active/Active Clustering
Hardware :
Power supply : Single, Fixed 250W
Fans : Dual, Fixed
Input power : 100-240 VAC, 60-50 Hz
Maximum power consumption (W) : 74.3
MTBF @25ºC in hours : 146,789
MTBF @25ºC in years : 16.76
Form factor : 1U Rack Mountable
Dimensions : 1.75 x 19.1 x 17 in (4.5 x 48.5 x 43 cm)
Weight : 13.56 lb (6.15 kg)
WEEE weight : 14.24 lb (6.46 kg)
Shipping weight : 20.79lb (9.43 kg)
Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity : 10-90% non-condensing
Firewall general :
Operating system : SonicOS 6.5.1
Security processing cores : 4
Interfaces :
8 x 1-GbE,
1 GbE Management,
1 Console
Expansion:1 Expansion Slot (Rear)*, SD Card*
Management : CLI, SSH, Web UI, Capture Security Center, GMS, REST APIs
SSO users : 30,000
Maximum access points supported : 32
Logging : Analyzer, Local Log, Syslog
Firewall/VPN Performance:
Firewall inspection throughput : 1.9 Gbps
Full DPI throughput : 300 Mbps
Application inspection throughput : 700 Mbps
IPS throughput : 700 Mbps
Anti-malware inspection throughput : 400 Mbps
IMIX throughput : 600 Mbps
TLS/SSL decryption and inspection (DPI SSL) : 200 Mbps
VPN throughput : 1.1 Gbps
Connections per second : 15,000/sec
Maximum connections (SPI) : 500,000
Maximum connections (DPI) : 250,000
Default/Maximum connections (DPI SSL) : 1,000/1,000
VPN :
Site-to-site VPN tunnels : 250
IPSec VPN clients (max) : 10 (250)
SSL VPN NetExtender clients (max) : 2 (250)
Encryption/Authentication :DES, 3DES, AES (128, 192, 256-bit)/MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14v
Route-based VPN : RIP, OSPF, BGP
Networking :
IP address assignment : Static (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP Relay
NAT modes : 1:1, many:1, 1:many, flexible NAT (overlapping IPS), PAT, transparent mode
VLAN interfaces : 256
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1p
Authentication : LDAP (multiple domains), XAUTH/RADIUS, SSO, Novell, internal user database, Terminal Services, Citrix, Common Access Card (CAC)
VoIP : Full H323-v1-5, SIP
Standards : TCP/IP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : ICSA Firewall, ICSA Anti-Virus, FIPS 140-2, Common Criteria NDPP (Firewall and IPS), UC APL
High availability : Active/Passive with State Sync
Hardware :
Power supply : Single, Fixed 200W
Fans : Dual, Fixed
Input power : 100-240 VAC, 60-50 Hz
Maximum power consumption (W) : 49.4
MTBF @25ºC in hours : 176,540
MTBF @25ºC in years : 20.15
Form factor : 1U Rack Mountable
Dimensions : 1.75 x 10.25 x 17 in(4.5 x 26 x 43 cm)
Weight : 10.1 lb (4.6 kg)
WEEE weight : 11.0 lb (5.0 kg)
Shipping weight : 14.3 lb (6.5 kg)
Major regulatory : FCC Class A, CE (EMC, LVD, RoHS), C-Tick, VCCI Class A, MSIP/KCC Class A, UL, cUL, TUV/GS, CB, Mexico CoC by UL, WEEE , REACH, ANATEL, BSMI, CU
Environment (Operating/Storage) : 32°-105° F (0°-40° C)/-40° to 158° F (-40° to 70° C)
Humidity : 10-90% non-condensing
Performance Overview:
Operating system : SonicOS 5.9.x – Wired / SonicOS 6.2.x – Wireless
Security Processor: 2x400 MHz (Wired) / 2x800 MHz (Wireless)
Memory (RAM): 512 MB (Wired) /1 GB (Wireless)
1 GbE Copper interfaces : 5
Expansion : USB
Firewall inspection throughput: 300 Mbps
Full DPI throughput:50 Mbps
Application inspection throughput:0
IPS throughput : 100 Mbps
Anti-malware inspection throughput : 50 Mbps
IMIX throughput : 60 Mbps
SSL Inspection and Decryption (DPI SSL) :15 Mbps
VPN throughput : 100 Mbps
Connections per second : 1,800
Maximum connections (SPI) : 10,000
Maximum connections (DPI) : 10,000
Single Sign-On (SSO) Users :250
VLAN interfaces : 25
SonicPoints supported (Maximum) : 2
VPN :
Site-to-Site VPN Tunnels : 10
IPSec VPN clients (Maximum) : 1 (5)
SSL VPN licenses (Maximum) : 1 (10)
Virtual assist bundled (Maximum) : No
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : No
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 150
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : No
Hardware:
Form factor : Desktop
Power Supply (W) : 24W external
Maximum power consumption (W) : 6.4 / 11.3
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 21.8 / 38.7 BTU
Dimensions : 3.6x14.1x19cm
Weight : 0.34 Kg / 0.75 lbs & 0.48 Kg / 1.06 lbs
WEEE weight : 0.80 Kg / 1.76 lbs & 0.94 Kg / 2.07 lbs
Shipping weight : 1.20 Kg / 2.64 lbs & 1.34 Kg / 2.95 lbs
MTBF (Years) : 30 / 15
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
Performance Overview:
Operating system : SonicOS 6.2.x
Security Processor: 2x 800 MHz
Memory (RAM): 1 GB
1 GbE Copper interfaces : 5
Expansion : USB
Firewall inspection throughput: 750 Mbps
Full DPI throughput:100 Mbps
Application inspection throughput:300 Mbps
IPS throughput : 300 Mbps
Anti-malware inspection throughput : 100 Mbps
IMIX throughput : 200 Mbps
SSL Inspection and Decryption (DPI SSL) :45 Mbps
VPN throughput : 300 Mbps
Connections per second : 5,000
Maximum connections (SPI) : 50,000
Maximum connections (DPI) : 50,000
Single Sign-On (SSO) Users :500
VLAN interfaces : 25
SonicPoints supported (Maximum) : 8
VPN :
Site-to-Site VPN Tunnels : 10
IPSec VPN clients (Maximum) : 1 (10)
SSL VPN licenses (Maximum) : 1 (50)
Virtual assist bundled (Maximum) : 1 (30-day trial)
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : Yes
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 150
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : Active/Standby
Hardware:
Form factor : Desktop
Power Supply (W) : 24W external
Maximum power consumption (W) : 6.9 / 12.0
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 23.5 / 40.9 BTU
Dimensions : 3.5x13.4x19cm
Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
MTBF (Years) : 28 / 14
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
Performance Overview:
Operating system : SonicOS 6.2.x
Security Processor: 2x 800 MHz
Memory (RAM): 1 GB
1 GbE Copper interfaces : 5
Expansion : USB
Firewall inspection throughput: 750 Mbps
Full DPI throughput:100 Mbps
Application inspection throughput:300 Mbps
IPS throughput : 300 Mbps
Anti-malware inspection throughput : 100 Mbps
IMIX throughput : 200 Mbps
SSL Inspection and Decryption (DPI SSL) :45 Mbps
VPN throughput : 300 Mbps
Connections per second : 5,000
Maximum connections (SPI) : 50,000
Maximum connections (DPI) : 50,000
Single Sign-On (SSO) Users :500
VLAN interfaces : 25
SonicPoints supported (Maximum) : 8
VPN :
Site-to-Site VPN Tunnels : 10
IPSec VPN clients (Maximum) : 1 (10)
SSL VPN licenses (Maximum) : 1 (50)
Virtual assist bundled (Maximum) : 1 (30-day trial)
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : Yes
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 150
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : Active/Standby
Hardware:
Form factor : Desktop
Power Supply (W) : 24W external
Maximum power consumption (W) : 6.9 / 12.0
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 23.5 / 40.9 BTU
Dimensions : 3.5x13.4x19cm
Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
MTBF (Years) : 28 / 14
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
Performance Overview:
Security Processor: 4x 800 MHz
Memory (RAM): 1 GB
1 GbE Copper interfaces : 7
Expansion : USB
Firewall inspection throughput: 1.3 Gbps
Full DPI throughput:300Mbps
Application inspection throughput:900Mbps
IPS throughput : 900Mbps
Anti-malware inspection throughput : 300Mbps
IMIX throughput : 500Mbps
SSL Inspection and Decryption (DPI SSL) : 100Mbps
VPN throughput : 900 Mbps
Connections per second : 6,000
Maximum connections (SPI) : 100,000
Maximum connections (DPI) : 90,000
Single Sign-On (SSO) Users :500
VLAN interfaces : 50
SonicPoints supported (Maximum) : 16
VPN :
Site-to-Site VPN Tunnels : 20
IPSec VPN clients (Maximum) : 2 (25)
SSL VPN licenses (Maximum) : 2 (100)
Virtual assist bundled (Maximum) : 1 (30-day trial)
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : Yes
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 250
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : Active/Standby
Hardware:
Form factor : Desktop
Power Supply (W) : 24W external
Maximum power consumption (W) : 9.2 / 13.8
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 31.3 / 47.1 BTU
Dimensions : 3.6x14.1x19cm
Weight : 0.73 Kg / 1.61 lbs & 0.84 Kg / 1.85 lbs
WEEE weight : 1.15 Kg / 2.53 lbs & 1.26 Kg / 2.78 lbs
Shipping weight : 1.37 Kg / 3.02 lbs & 1.48 Kg / 3.26 lbs
MTBF (Years) : 27 / 13
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
Performance Overview:
Security Processor: 4x 1 GHz
Memory (RAM): 1 GB
1 GbE Copper interfaces : 8
Expansion : USB
Firewall inspection throughput: 1.4 Gbps
Full DPI throughput: 400 Mbps
Application inspection throughput:1.0 Gbps
IPS throughput : 1.0 Gbps
Anti-malware inspection throughput : 400 Mbps
IMIX throughput : 700 Mbps
SSL Inspection and Decryption (DPI SSL) :150 Mbps
VPN throughput : 1.0 Gbps
Connections per second : 8,000
Maximum connections (SPI) : 125,000
Maximum connections (DPI) : 100,000
Single Sign-On (SSO) Users : 500
VLAN interfaces : 50
SonicPoints supported (Maximum) : 16
VPN :
Site-to-Site VPN Tunnels : 25
IPSec VPN clients (Maximum) : 2 (25)
SSL VPN licenses (Maximum) : 2 (150)
Virtual assist bundled (Maximum) : 1 (30-day trial)
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : Yes
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 150
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : Active/Standby with stateful synchronization
Hardware:
Form factor : Desktop
Power Supply (W) : 36W external
Maximum power consumption (W) : 13.4 / 17.7
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 45.9 / 60.5 BTU
Dimensions : 3.5x15x22.5cm
Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
MTBF (Years) : 20 / 12
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
Performance Overview:
Security Processor: 4x 1.4 GHz
Memory (RAM): 1 GB
1 GbE Copper interfaces : 10
Expansion : Expansion Slot (Rear), 2 USB
Firewall inspection throughput: 1.5 Gbps
Full DPI throughput: 500 Mbps
Application inspection throughput:1.1 Gbps
IPS throughput : 1.1 Gbps
Anti-malware inspection throughput : 500 Mbps
IMIX throughput : 900 Mbps
SSL Inspection and Decryption (DPI SSL) :200 Mbps
VPN throughput : 1.1 Gbps
Connections per second : 12,000
Maximum connections (SPI) : 150,000
Maximum connections (DPI) : 125,000
Single Sign-On (SSO) Users : 500
VLAN interfaces : 50
SonicPoints supported (Maximum) : 24
VPN :
Site-to-Site VPN Tunnels : 50
IPSec VPN clients (Maximum) : 2 (25)
SSL VPN licenses (Maximum) : 2 (200)
Virtual assist bundled (Maximum) : 1 (30-day trial)
Encryption/Authentication : DES, 3DES, AES (128, 192, 256-bit), MD5, SHA-1, Suite B Cryptography
Key exchange : Diffie Hellman Groups 1, 2, 5, 14
Route-based VPN : RIP, OSPF
Certificate support : Verisign, Thawte, Cybertrust, RSA Keon, Entrust and Microsoft CA for SonicWall-to-SonicWall VPN, SCEP
VPN features : Dead Peer Detection, DHCP Over VPN, IPSec NAT Traversal, Redundant VPN Gateway, Route-based VPN
Global VPN client platforms supported : Microsoft® Windows Vista 32/64-bit, Windows 7 32/64-bit, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit
NetExtender : Microsoft Windows Vista 32/64-bit, Windows 7, Windows 8.0 32/64-bit, Windows 8.1 32/64-bit, Mac OS X 10.4+, Linux FC3+/Ubuntu 7+/OpenSUSE
Mobile Connect : Apple® iOS, Mac OS X, Google® Android™, Kindle Fire, Windows 8.1 (Embedded)
Security Services:
Deep Packet Inspection services : Gateway Anti-Virus, Anti-Spyware, Intrusion Prevention, DPI SSL
Content Filtering Service (CFS) : HTTP URL, HTTPS IP, keyword and content scanning, Comprehensive filtering based on file types such as ActiveX, Java, Cookies for privacy, allow/forbid lists
Enforced Client Anti-Virus and Anti-Spyware : McAfee®
Comprehensive Anti-Spam Service : Supported
Application Intelligence and Control : Yes
Application Visualization : Yes
Networking:
IP address assignment : Static, (DHCP, PPPoE, L2TP and PPTP client), Internal DHCP server, DHCP relay
NAT modes : 1:1, 1:many, many:1, many:many, flexible NAT (overlapping IPs), PAT, transparent mode
Routing protocols : BGP, OSPF, RIPv1/v2, static routes, policy-based routing, multicast
QoS : Bandwidth priority, max bandwidth, guaranteed bandwidth, DSCP marking, 802.1e (WMM)
Authentication : XAUTH/RADIUS, Active Directory, SSO, LDAP, Novell, internal user database, Terminal Services, Citrix
Local user database : 150
VoIP : Full H.323v1-5, SIP
Standards : TCP/IP, UDP, ICMP, HTTP, HTTPS, IPSec, ISAKMP/IKE, SNMP, DHCP, PPPoE, L2TP, PPTP, RADIUS, IEEE 802.3
Certifications : VPNC, IPv6 (Phase 2)
Certifications pending : Common Criteria NDPP, FIPS 140-2 (with Suite B) Level 2, ICSA Firewall, ICSA Anti-virus, UC APL
Common Access Card (CAC) : Supported
High Availability : Active/Standby with stateful synchronization
Hardware:
Form factor : Desktop
Power Supply (W) : 36W external
Maximum power consumption (W) : 13.4 / 17.7
Input power : 100 to 240 VAC, 50-60 Hz, 1 A
Total heat dissipation : 45.9 / 60.5 BTU
Dimensions : 3.5x15x22.5cm
Weight : 0.92 Kg / 2.03 lbs & 1.05 Kg / 2.31 lbs
WEEE weight : 1.34 Kg / 2.95 lbs & 1.48 Kg / 3.26 lbs
Shipping weight : 1.93 Kg / 4.25 lbs & 2.07 Kg / 4.56 lbs
MTBF (Years) : 20 / 12
Environment : 40-105° F, 0-40° C
Humidity : 5-95% non-condensing
